Elevate Your Home With Sky Only Views
Pitched roof
The Glazing Vision Pitchglaze Roof Window is a UKCA and CE marked roof window designed to be installed in pitched tiled roof applications flush with the tiling line, providing you with a vast amount of natural daylight through the internal 'Sky Only Views' which is something not usually found with other roof windows on the market.
The Fixed Pitchglaze Roof Window can be supplied in either landscape or portrait orientations and is designed to be used in roof pitches between 15° and 60°. It features a Qualicoat approved polyester powder coated aluminium frame combined with either double or triple glazing.
Thanks to its minimalistic internal finish, the Pitchglaze Roof Window enhances the visual impact of any interior space by providing a seamless connection to the outside nature, so whether you are designing a contemporary home or specifying roof glazing for a refurbishment project, the Pitchglaze Roof Window offers a refined solution that balances aesthetic appeal with high-performance glazing.
Selected sizes of this product are available to buy immediately on our online shop.
Buy now on rooflights.comKey features
Optional extras
Specification
Min span |
300mm |
Max span |
3000mm |
Min width |
300mm |
Max width |
3000mm |
Min roof pitch |
15 degrees |
Max roof pitch |
85 degrees |
Note that the minimum and maximum span, width and pitch are dependent on various factors, your technical sales advisor will be happy to advise on these. Further information on upstand requirements and product dimensions can be found on our website or by contacting your technical sales advisor.
Structural integrity of the Pitchglaze Roof Window is assured through the use of finite element analysis (FEA) and testing. Further information and specific performance details can be obtained from your Technical Sales Advisor.
The Pitchglaze Roof Window has been expertly designed with security as a priority - The product has been extensively tested and is UKCA and CE marked in accordance with EN 143511:2006+A2:2016.
It has achieved the following classification results:
(Size: 1000 mm span x 3000 mm width, Pitch: 15°)
Air permeability - EN 12207 - Class 4, ±750 Pa
Watertightness - EN 12208 - Class E750, 750 Pa
Wind resistance - EN 12210 - Class E2400, ±2400 Pa Serviceability & ±3600 Pa Safety
Please contact our team if you have off-spec requirements for dimensions, glass or anything else, we’ll be happy to assist
Standards
Awards and certifications
Made in Britain
Glazing Vision rooflights are assembled on site in our rural Norfolk factory to ensure a high quality product - Made in Britain, trusted internationally.
UKCA & CE Marked
Select Glazing Vision Rooflights and Roof Windows are UKCA & CE Marked after undergoing extensive testing.
ISO 9001 & ISO 14001
Glazing Vision operates to BSI ISO9001 and ISO14001 standards to ensure high quality rooflights
RIBA Providers Network member
Glazing Vision provides a number of comprehensive RIBA Certified CPDs to the architectural community.
QualiCoat Applicator
Glazing Vision rooflights feature QualiCoat approved aluminum framework to ensure a high quality paint finish
Compare with other products
Access
Fire rated
Flat roof
Pitched roof
Residential
Ventilation
Walk on
Pitchglaze Fixed Roof Window
Pitchvent Roof Window
Pitchridge Fixed Roof Window
Flushglaze Fixed Rooflight
Flushglaze Fixed Multipart Rooflight
Flushglaze Eaves Rooflight
Manuals & guides
CAD & BIM
Frequently Asked Questions
Glazing Vision understands that choosing the right rooflight or roof window for your property is an important decision. To help, we've compiled answers to some of the most frequently asked questions about our Pitchglaze Roof Window - If you have a question that is not listed here, feel free to contact our experienced team.
Glazing Vision does not sell “traditional” windows, we specialise in the manufacture of roof windows; Roof windows are specifically designed to be installed flush with the roof tiles at a pitch of 15-60 degrees. Unlike traditional windows, Glazing Vision roof windows provide you with uninterrupted views to the outside, increasing natural daylight flow.
No, as the FENSA certification scheme does not apply to rooflights, and does not apply if the roof window is a new addition to your property - You will require approval from Building Control if this is the case.
A Rooflight is designed to be installed on an upstand, at a standard pitch range of 5-70 degrees, whereas a roof window is designed to be installed flush with the roof tiles at a steeper pitch range of 15-60 degrees.
Lead times vary per product as they are carefully assembled and tested in-house, but your local Technical Sales Manager can advise you of our latest lead times.
Related Case Studies
The Pitchglaze Roof Window has transformed many properties around the world through the unparalleled transformative power of natural daylight
